Outside Broadcast Unit
Our IP-based micro broadcast vehicle — built for high-performance production without the footprint.
Enquire About HireOB4 is FLX Technical's flagship outside broadcast unit. Designed from the ground up for IP-based production workflows, it delivers broadcast-grade performance in a compact, sustainable package suitable for venues and events where traditional OB trucks simply aren't viable.
Low Power Consumption: Ideal for venues with power constraints or sustainability targets.
Micro Footprint: Access venues and locations that full-size OB trucks cannot reach.
Full IP Workflow: Built around modern IP infrastructure for flexible, future-proof production.
Switching:
vMix on Dedicated Hardware
Camera Channels:
4 Channels + PTZ & Fixed
Supported Formats:
HD / UHD
Monitoring:
Expandable IP Multiviewer 8x Internal + 4x External
Frame:
BMD Fairlight on dedicated hardware.
Surface:
Behringer XTouch.
Input Channels:
Up to 128.
I/O:
Local XLR/ Dante Remote.
Monitoring:
Local: 2x Yamaha MSP5.
Microphones:
Wireless Mics & Presenter IFB available on request.
Signal Transport:
NewTek NDI / OMT
Bonded 4G/5G:
Yes
Fibre:
Up to 1 km fibre for remote racks available
Comms:
Digital Matrix Intercom
Network:
100Gbe IP Backbone with 20Gbe links to all racks and external I/O
Base:
Indespension 3500KG Twin Axle Trailer
Power:
2x 32A Single Phase Supplies Required
1x Production | 1x Comfort
Crew Capacity: 4
Actual Weight:
3200 KG (Loaded)
Dimensions: 4000 x 2200 x 2500 (LxWxH) mm
Get in touch to check availability, discuss your production requirements, or request a full technical rider.
